1). The controller has 3 output signal channel which the line sequence should be right.
2). Using DC 12V or DC 24V as controller driver, do not use normal high voltage driver.


Function Descriptions
1. 16 changing patterns
2. Static light adjustable, dynamic speed adjustable
3. Power lost memory function
4. Touch interface, RGB all color touch interface pulley

Technical Parameters
● working temperature: -20-60 ℃
● supply voltage: DC12~24
● output: 3 channels
● connection mode: common anode
● external dimension: L86 Χ W86Χ H37mm
● packing size: L100 Χ W100 Χ H60 mm
● net weight: 185g
● gross weight: 215g
● output current: <4A( each channel )
● output power: 12V<144W,24V<288W

Application:
1.) Instead of the traditional incandescent lamp.
2.) Meeting rooms/school classrooms/office buildings.
3.) Hospitals/factories/,hotels.
4.) Supermarkets/home lighting.
5.) Other commercial and residential place
